Product Details
Place of Origin: China
Brand Name: Konja
Certification: CE
Payment & Shipping Terms
Minimum Order Quantity: 30 pcs
Packaging Details: Carton+Wooden
Delivery Time: 7-30 days
Payment Terms: T/T
Supply Ability: 1000Pcs Per Month
Voltage: |
51.2V |
Capacity: |
100Ah 200Ah 300Ah |
Weight: |
50kg |
IP LEVEL: |
IP20 |
Cycle Life: |
6000 Cycles @ 0.2C 25°C 80%D.O.D |
Warranty: |
5 Years |
Voltage: |
51.2V |
Capacity: |
100Ah 200Ah 300Ah |
Weight: |
50kg |
IP LEVEL: |
IP20 |
Cycle Life: |
6000 Cycles @ 0.2C 25°C 80%D.O.D |
Warranty: |
5 Years |
1. Our Stackable Battery Pack is a reliable and effective stackable power source that can be used for a variety of applications.
2. It is designed to provide high capacity and cycle life of up to 6000 cycles @ 0.2C 25°C 80%D.O.D.
3. The battery and inverter weight are only 90-190kg, and is available in capacities of 100Ah, 200Ah, 300Ah.
4. It is IP20 rated, but it can be with IP65 making it suitable for outdoor use in all weather conditions.
5. With a 5 year warranty, you can be sure that this stackable power source will provide you with long-lasting and reliable service.
1.Product Name: Stackable Battery Pack
2.Capacity: 100Ah 200Ah 300Ah
3.Cycle life: 6000 cycles @ 0.2C 25°C 80%D.O.D
4.Weight: 90kg-190kg
5.Warranty: 5 Years
6. Voltage: 51.2V
7.Special Features: Stackable Battery Module, Rechargeable Battery Pack, Stackable Battery Module
Product Attribute | Technical Parameter | ||
---|---|---|---|
Battery type
|
LFP
|
||
Battery distribution unit
|
GPOWER-B
|
||
Battery module
|
5.12KWh
|
||
Number of battery modules
|
1 | 2 | 3 |
Battery total energy
|
5.12kWh
|
10.24kWh
|
15.36kWh
|
Nominal capacity
|
100Ah
|
200Ah
|
300Ah
|
Rated voltage
|
51.2V | ||
Voltage range for full load
|
44.8-58.4V
|
||
Max. Discharge Current [A]
|
100A
|
200A
|
250A
|
Rated charge/discharge current
|
20A
|
40A
|
60A
|
Degree of protection
|
IP20
|
||
Ambient temperature range
|
-20°C ~ 60°C
|
||
Allowable relative humidity range
|
5~95%
|
||
Max. operating altitude
|
2000 m
|
||
Installation
|
Floor stand
|
||
Cooling
|
Natural
|
||
Display
|
LED indicators
|
||
Communication
|
CAN/RS485/RS232
|
||
Certificates
|
IEC62619, TUV, ROHS, UN38.3, CEI, VDE, MSDS,CE Standard
|
||
Battery Module
|
|||
Battery module energy
|
5.12kWh
|
||
Standard charge and discharge current
|
50A | ||
Dimension
|
W640*D470*H210mm
|
||
Weight
|
50KG |
KonJa Power Stackable Battery Module is designed to provide high-capacity battery packs for more efficient energy storage. With a nominal voltage of 51.2V, the lithium-ion cells offer long-term durability with capacity of 100Ah, 200Ah, 300Ah. The battery pack has an IP20 level of protection to ensure safety and is available with a 5 years warranty. With a weight of 50kg, the Konja Stackable Battery Module is able to store more energy than traditional battery packs while being easily stackable. With minimum order quantity of 30 pcs and delivery time of 7-30 days, the supply ability is 1000Pcs per month. The product comes in a carton and wooden packaging. KonJa Power Stackable Battery Module is perfect for those who need high-capacity and long-term durability battery packs.
The Stackable Battery Pack will be packaged in a box made of corrugated cardboard. It will be secured with bubble wrap and placed inside of a larger box for shipping. The larger box will also be made of corrugated cardboard and will be sealed with packing tape. There will be a label on the box with the product name, address, and other shipping information.
Q: What is the brand name of the Stackable Battery Pack?
A: The brand name is KonJa.
Q: Where is the Stackable Battery Pack manufactured?
A: The Stackable Battery Pack is manufactured in China.
Q: What is the minimum order quantity?
A: The minimum order quantity is 30 pcs.
Q: How will the Stackable Battery Pack be packaged?
A: The Stackable Battery Pack will be packaged in a carton and wooden box.
Q: How long will delivery take?
A: Delivery will take 7-30 days.
Q: What payment terms are available?
A: Payment terms are T/T.
Q: How many Stackable Battery Pack can be supplied per month?
A: We can supply up to 1000Pcs per month.
